New Design Fat Tire Electric Bike 500w Lithium Battery Electric Bicycles 20inch Aluminum Alloy Frame Ebike

New Design Fat Tire Electric Bike 500w Lithium Battery Electric Bicycles 20inch Aluminum Alloy Frame Ebike



Product Paramenters

New design Fat Tire electric bike 500w Lithium Battery electric bicycles 20inch Aluminum Alloy Frame ebike

Electric system

Main components

Motor

48V500W brushless rear drive

Frame

Al alloy/ frame size can be 16'', 17'', 18'', etc.

Battery

48v15.6ah etc lithium battery

Tyre

20*4.0 tyre SONGXIA brand.

Display

LCD display

Wheel

20 inch*4.0 spoked wheel

Throttle

twist/thum throttle

Charging time

5-6 hours

Charger

100v-240v, 48v 2A

Brake lever

power cut off when braking

PAS

5 classes PAS+ curise

Brake

front+ rear disc brake

Fork

Suspension with lock & aluminaum

Derailleur

6 speeds/7 speeds, SHIMANO brand

Chain

Anti-rust, KMC brand

Lights

LED for front & rear

Handlebar

Alunimum alloy

Display

LCD SW900 brand diaplay

Pedals

Aluminum alloy & Plastic WEIGE brand

Saddle

Soft & comfortable two-seat

Performance

Tube

with inner tube/ tubeless available.

Max. speed

28km/h

Handlebar

Al alloy

Range

50-60km

Derailleur

Shimano

Max. load

150kgs

Stem

AL alloy

Net weight

32KG

Seat post

AL alloy

Gross weight

34KG

Open size

1620*270*850MM

Package

7 layers carton

Chain wheel

52T

Products Description

Details Images
